Manning Lighting
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1-TST
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1-CBL
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M2-TST
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M3
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M5
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M4
LP-272-PT(WHT)-WH-P88-35-D0-120-M6
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1 Hover to Zoom
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1 — download hi-res image
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1-TST
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1-TST — download image
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1-CBL
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M1-CBL — download image
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M2-TST Hover to Zoom
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M2-TST — download hi-res image
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M3 Hover to Zoom
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M3 — download hi-res image
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M5 Hover to Zoom
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M5 — download hi-res image
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M4 Hover to Zoom
LP-272-PT(WHT)-PT(WHT)-P88-35-D0-B60-120-WH-M4 — download hi-res image
LP-272-PT(WHT)-WH-P88-35-D0-120-M6 Hover to Zoom
LP-272-PT(WHT)-WH-P88-35-D0-120-M6 — download hi-res image

Milan Pendant

Tags: distinctive, customize, panels, LED

The award-winning Milan pendant features elegant curved panels in six standard patterns surrounding an acrylic inner diffuser. Panel finishes include wood veneer, brushed or grinder finish aluminum, or painted. Incandescent or energy saving LED or fluorescent options are available for maximum efficiency and performance.

Spec Sheet (PDF) Find a Rep Contact Us

Fixtures

LP-270

W: 13.25" x H: 26.75" x L: 13.25"     OAH: 52''

LED

  • P27 Body only w/bottom lens (27W)
    • Lumens: 2730 (delivered)
    • Wattage: 27
  • P63 Body (27w) + Downlight (36w)
    • Lumens: 5471 (delivered)
    • Wattage: 63
  • Downlight Optic Options
    • B60 - 60-deg. beam reflector
    • B90 - 90-deg. beam reflector
    • ECR - Black Egg Crate Louver (approx. 40-deg. beam)
  • CCT: 27K, 30K, 35K, 40K
  • CRI: >80
  • L70 @ 50,000 hrs.
  • Dimming options
    • D0:0-10v
    • D1:Triac (Leading Edge)*
    • D2:ELV (Trailing Edge)

  • 1N200 200 watt A-21 med. base

LP-272

W: 16.25" x H: 33.25" x L: 16.25"     OAH: 71''

LED

  • P40 Body only w/bottom lens (40w)
    • Lumens: 3796 (delivered)
    • Wattage: 40
  • P88 Body (40w) + Downlight (48w)
    • Lumens: 8128 (delivered)
    • Wattage: 88
  • Downlight Optic Options
    • B60 - 60-deg. beam reflector
    • B90 - 90-deg. beam reflector
    • ECR - Black Egg Crate Louver (approx. 40-deg. beam)
  • CCT: 27K, 30K, 35K, 40K
  • CRI: >80
  • L70 @ 50,000 hrs.
  • Dimming options
    • D0:0-10v
    • D1:Triac (Leading Edge)*
    • D2:ELV (Trailing Edge)

  • 8N100 / 1R300 (8) 100 watt incandescent (1) 300 watt R40 med. base

LP-274

W: 19.25" x H: 39" x L: 19.25"     OAH: 89''

LED

  • P54 Body only w/bottom lens (54w)
    • Lumens: 5555 (delivered)
    • Wattage: 54
  • P109 Body (54w) + Downlight (55w)
    • Lumens: 11760 (delivered)
    • Wattage: 109
  • P150 Body (54w) + Downlight (96w)
    • Lumens: 14818 (delivered)
    • Wattage: 150
  • Downlight Optic Options
    • B60 - 60-deg. beam reflector
    • B90 - 90-deg. beam reflector
    • ECR - Black Egg Crate Louver (approx. 40-deg. beam)
  • CCT: 27K, 30K, 35K, 40K
  • CRI: >80
  • L70 @ 50,000 hrs.
  • Dimming options
    • D0:0-10v
    • D1:Triac (Leading Edge)*
    • D2:ELV (Trailing Edge)

  • 10N100 / 1R500 (10) 100 watt incandescent (1) 500 watt R40 med. base

Finish Codes:
Trim: PT
Panels: BA or PT or WV



Standard Painted Finishes (PT)

Specify PT(XXX).

White (WHT)
Warm Grey (WMG)
Cool Grey (CLG)
Black (BLK)
Light Gold (LGD)
Medium Gold (MGD)
Light Titanium (LTM)
Medium Titanium (MTM)
Light Silver (LSV)
Medium Silver (MSV)
Deep Silver (DSV)
Light Bronze (LBZ)
Medium Bronze (MBZ)
Deep Bronze (DBZ)
Medium Copper (MCP)
Deep Copper (DCP)
Cream (CRM)
Textured Silver (TSV)
Textured Nickel (TNK)
Deep Gold (DGD)
Bright Copper (BCP)
Aged Copper (ACP)
Textured Copper (TCP)
Light Copper (LCP)
Silverado (SD)
Bronze Crater (BC)
Oil Rubbed Bronze (ORB)

Brushed Solid Aluminum (BA)

Brushed Solid Aluminum (BA)

Wood Veneer (WV)

Specify WV(XXX).

Maple Veneer (MPL)
Cherry Veneer (CHR)
Light Oak Veneer (LOK)

NOTE: Computer monitors do not show colors accurately. These finishes should be used only as a rough guide. Consult with your Manning Representative for actual color samples.

Diffuser Codes: WH



Opal White Acrylic (WH)

Opal White Acrylic (WH)

Slot Panel Milan (M1)
Slot Panel Milan (M1)
4Square Panel Milan (M2)
4Square Panel Milan (M2)
Gothic Panel Milan (M3)
Gothic Panel Milan (M3)
Newcross Panel Milan (M4)
Newcross Panel Milan (M4)
Welsh Panel Milan (M5)
Welsh Panel Milan (M5)
Oldcross Panel Milan (M6)
Oldcross Panel Milan (M6)

Single Stem (SIN)
Single Stem (SIN)
Aircraft Cable (CBL)
Aircraft Cable (CBL)
Satellite Rods (QAD)
Satellite Rods (QAD)
Angled Rods (TST)
Angled Rods (TST)

  1. OAH is standard unless specified.
  2. FINISH: Finish is low VOC thermo-cure powdercoat paint or clear lacquer. Specify three digit color suffix with "PT" finish options.
  3. HOUSING: Solid aluminum top and bottom end caps, extruded aluminum corner posts and laser-cut aluminum accent panels and bar details.
  4. MOUNTING: Fixture supplied with painted canopy, 45-degree swivel ball and hanger for mounting to standard octagon junction box.
  5. CIRCUITS: Dual-level circuiting for interior lamps/downlight standard.
  6. ETL listed to UL standards for dry and damp locations
  7. *Surge protection recommended for use with D1 (Triac/Leading Edge) dimming systems.

Other Milan Fixtures

Milan Sconce

Milan Sconce
Milan Ceiling

Milan Ceiling

View All Milan Fixtures
